Superior Benifits :

◆ Dimension : 335x70x19 mm

◆ Real stainless steel 304 panels and handles

◆ self-error detective, very durable and attractive.

◆ Warranty is 2 years

◆ Can update to TTHOTEL Online Lock System. Hotels Can Have Real Time Room Status,

Open Any Room Locks and Turn On/Off Any Room's Power Remotely , Issue/Cancel Any Room's Guest Card Or Password Remotely....etc

◆ Can realize " One Card System ", Wall Reader and Elevator Controller are available to be integrated with hotel elevator,

     parking barrier system, common doors, swimming poor doors, restaurant doors, POS...etc.

◆ CE, FCC certified

◆ Adopt Japan MABUCHI micro-motors which ensure 500,000 running times without problems.

◆ RFID Mifare PHILIPS technology, 100,000 times write life for keycard, contactless reading keycard.

◆ ANSI / US Standard mortises

◆ Free-rotating while locked

◆ Powered by 4 units of AA batteries, easy replacement.

◆ Openings 20,000 times for one new battery pack.

◆ Mifare card and RF card versions are available.

◆ Lower power alarm voltage : 4.8V ( still able to open about 100 times )

◆ Meeting passage mode is actived by passage card for meeting case.

◆ 3 public passage modes : Hotel Passage, Building Passage and Floor Passage.

◆ Do not disturb ( D.N.D )function is available : while dead bolt is on from inside, the lock will refuse keycard from outside by red light blinking.

◆ Panic release function : the deadbolt and latch are automatically retracted by inside handle pressing to easy egress when emergency happens.

◆ For 35-75mm thickness doors

Card Useage:

◆ Guest Card : Issued from reception to open its own room with expiration date.

◆ Master Card : Hold by management or GM or Manager to access all rooms of hotel( even locked by deadbolt ).

◆ Floor Card : Hold by clean staff to enter the rooms in one floor.

◆ Building Card : Hold by Manager to enter the rooms in one building.

◆ Lost Card : To suspend the lost guest cards.

◆ Emergency Card : Enter all rooms when emergency happens, and the rooms will stay open.

◆ Group Card : Can open all rooms you selected in one Group. random rooms.

Technicial Features :

◆ Power : 6V / 4 x AA batteries

◆ Card : RF ( 125KHz ) and Mifare ( 13.56MHz ) Cards are available.

◆ Inductive Distance : 2-5 CM

◆ Working Temperature : -30℃～60℃

◆ Working Humidity : 15~85% RH

◆ Static current : < 10uA

◆ Working current : < 150mA

◆ Unlock record : The latest 350 records is available

◆ Gross Weight : 2.8 KGS

◆ Package : 10 Locks / box , 61.5x39.5x38.5 MM / carton.

◆ Open mode : Card and Mechanical keys.
