Main Features:
5 Unlock Ways :
1. Phone APP Unlock (via bluetooth, or add Gateway to realize remote open )
2. Fingerprint Unlock
3. Password Unlock
4. Metal Key
5. AI Voice (Alexa and Google Home, need add gateway)
Parameter:
Unlock ways: Fingerprint, TT LOCK APP, WIFI, Passcode , Mechnical key, Al Alexa and google home
Material: 304 stainless steel panel, zinc alloy handle
Color: silver, black with Red bronze
Suitable for: wooden doors, aluminum doors
Data Capacity: 110pcs fingerprint
Reader Item SIZE: 150mm*65mm*40mm
Weight: 1.5kgs
Certification: CE/ROHS
Working Voltage: 6V(4*AAA batteries)
Applicable for door thickness:
Standard Edition 30mm-55mm
Custom Edition 30mm-100mm
Applicable for door frame wideness: 50mm or above
Handle Reversible: Yes
Available Mortise: 60 or 70 single latch
Working Temperature: -20~70℃
Battery life span: support 100000 times unlock operations
Specifications :
| 1. Weight : | 1.5 KGS |
| 2. Size : | 150 x 25 MM for handle, 70 x 70MM for panel |
| 3. Static Load : | < 11Ua |
| 4. Working Load : | 100Ma-150Ma |
| 5. Humidity : | 10%-95% |
| 6. Working Tempreture : | -20℃~70℃ |
| 7. Material : | Stainless steel and Zinc Alloy |
| 8. Surface Treatment : | Chrome & Black |
| 9. Mortise : | Single Latch |
| 10. Identification Time | <0.1S |
| 11. Unlock Ways : | Fingerprint + Code + Key + TTLOCK APP + AI Voice |
| 12. Override Mechanical Key : | 2 PCS For Each Lock |
| 13. User Capacity : | 100 Fingerprint users + 100 Password users |
| 14. Power : | 4 AAA batteries / 6V. 18 Monthes' Duration |
| 15.Low Battery Warning : | Lower Than 4.8 V , can still use 100 times |
| 16. Application | Apartment ,office, airbnb or House door |
| 17. Certificates : | CE, FCC, ISO9001 |
Use 4pcs AAA 1.5V battery. (battery not include);
Support low power warning. Battery box in front handle. :
Lock Dimensions :
Easy Installtion:
Suitable for the door thickness 30-50mm, if your door is thicker, please contact us.
Both for wooden door and metal door and so on.
Latch size:
the latch can be adjusted to 60 or 70 mm freely.
With the gateway can work with the Alexa and Google Assistant
If not with gateway, the lock connect with the lock via bluetooth, it can manage the lock within the bluetooth arange, and also can make the Temporary password to the guest open lock remotely by phone APP. If with gateway, can connect with wifi, work with Alexa and Google Assistant. Control the lock remotely via internet.
About the mobile APP / TTLOCK
All the lock setting are in the TTLOCK APP, so it is very easy to use the lock.Only the Admind phone that can manage the lock, but you can authorized to your family as the admin that they also can manage the lock by his phone
Packing Details :
